RFID UHF Woven Laundry Tag

Dimension: 70x15x1.8 mm or 70x17x1.8mm

Tag Weight: 0.4g

Protocol: ISO/ICE 18000-6C EPC Class 1 Gen 2

MOQ: 1000 PCS

Share This Product:
  • Overview
  • Parameter
  • Application
  • Test Performance

Overview

  • RFID Laundry Tags is soft, flexible and thin tags,it can be applied quickly and easily in multiple ways - sewn, heat-sealed or pouched - according to your wash process needs.it was designed specifically to meet the rigors of high volume, high pressure wash workflows to help extend the life of your assets and have been tested in real-world laundries for over 200 cycles to ensure guaranteed tag performance and endurance.

Feature

  • 1. Waterproof, high temperature resistant
    2. Outstanding mechanical resistance ensures tag performance and endurance for reduced wear-and-tear
    3. Tested for over 200 cycles in real laundries!
    4. Suitable for autoclave
    5. best-in-class for confined field applications

a(mm)
70
70
70
b(mm)
17
15
14


Package


Physical:


Material
50/50 polycotton or full polyester
Dimension
70x15x1.8mm or 70x17x1.8mm
Antenna
Copper
Weight
0.4g/pcs
Reading Distance
Up to 6m
Protocol
ISO 18000-6C EPC Global Class Gen2
Tag Warranty
First of 200 wash

Features


Frequency
902~928MHz(US)
Chip
Monza R6-P
Write Endurance
100,000 Cycles
Data Retention
10 years
Working Life
Machine washable up to 200 cycles
Reading Distance
3m(fixed reader)

Environmental Parameter


Operating Power
Passive, operates through antenna's RF field
Typical Washing Cycle
Wash: 90℃@15min, Dry: 180℃@3min, Ironing: 200℃@12sec, Water Extractor: 60bar@80sec
Autoclave
Air Removal: 100℃@5min, 0.1bar
Sterilizing: 140℃@10min, 3.25bar
Drying: 45℃@15min,0.2bar
Patching Instructions
204℃@12sec, 0.5kg/m²
Storage Temperature
-40℃ ~ 120℃
Chemical Resistance
All chemicals common to the washing process

Specification


☆ World wide UHF supported

High security: UID, write protection

Multiple tags operation allowed

Logo printing, serial number, bar code allowed

Advanced RFID tag production technology ensured outstanding quality

Green products, ROHS, SGS compliance
